Box of 100

Product Self Drilling Metal Screw
Heads Painted: Yes
Colour Surfmist
Head Type: Wafer Head
Size: 10g (4.80mm)
Thread Pitch: 16 TPI
Thread: Coarse
Thread Direction: Right Hand
Corrosion Protection Level: Excellent
Internal or External: External
Class Grade: Class 3
Material: Hardened Steel
Finish: Galvanised
Length (l): 16mm
Product Diameter (d): 4.65 – 4.80mm
Head Diameter (a): 9.00 – 9.30mm
Head Height (h): 2.00mm
Drill Point Length (p): 5.50mm
Min to Max Steel Thickness: 0.75 – 3.50mm
Drive Size (as): PH2
Screw Point: Drill Point
Drive Type: Phillips
Single Shear (kN): 6.3
Axial Tensile (kN): 11.1
Torsional (Nm): 8.3
Recommended Drill Speed: Under 3000 rpm
Closest size in mm: 4.80mm
Closest size in imperial: 0.19″
Standard Made To: AS3566
Brand: Hobson Engineering
